Availability: 9 in stock
Engine: Mi-T-M OHV engine low-oil shutdown engine • Recoil starting system • Automatic idle control
Alternator: Brushed 120V/240V alternator • Copper and aluminum windings • Total harmonic distortion (THD) less than 6%
Frame: Low profile, compact design • Wraparound frame with 1-inch steel tubing • Wheel kit with tires and rubber gripped handles
Components: Easy-access and protected control panel with magnetic circuit breakers and GFCI-protected receptacles • Large low-tone mufflers • Engine on/off switch • Fuel shut-off valve • DC charging/battery charging
| Max. AC Output | 6000 watts |
| Rated AC Output | 5500 watts |
| Displacement/Engine | 389cc Mi-T-M OHV |
| Frequency/Voltage | 60Hz/120V/240V |
| Max. Amps (120V/240V) | 50.0/25.0 |
| Cont. Amps (120V/240V) | 45.8/22.9 |
| Receptacles | (2) 120V, 20A GFCI duplex, (1) 120V, 30A twist lock, (1) 120V/240V, 30A twist lock |
| Circuit Breakers | (1) Main circuit breaker, (2) 20A circuit breaker, single pole, (1) 10A DC breaker |
| Rated Speed | 3600 RPM |
| Fuel Capacity | 6.6 gallons |
| Run Time (at full load) | 6.5 hours |
| Net Weight | 180 lbs. |
| Shipping Weight | 228 lbs. |
| Length | 39.1 in. |
| Width | 28.67 in. |
| Height | 30.65 in |
