KEY BENEFITS
• Patented automatic arc return feature
returns the turret back to the original arc
pattern if vandalized; adjustable arc
50° to 360°
• Non-strippable drive mechanism is
protected from damage if turned in the
opposite direction of travel
• Part- and full-circle in one model for
installation flexibility and reduced inventory
• Color-coded nozzles make identification easy
• QuickCheck™ Arc Mechanism for fast
arc adjustment
• Available stainless steel riser for extra
durability
• Drain Check Valve prevents low-head
drainage (up to 10′ of elevation)
OPERATING SPECIFICATIONS
• Nozzle choices: 11
• Radius: 37′ to 71′
• Flow: 3.8 to 31.5 GPM
• Recommended pressure range:
40 to 100 PSI
• Operating pressure range: 40 to 100 PSI
• Precipitation rates: 0.4 in/hr
approximately
• Nozzle trajectory: standard = 25°
• Warranty period: 5 years
