KEY BENEFITS
• Headed and slotted setscrew allows radius adjustment with a Hunter
Wrench or flat-blade screwdriver
• Adjustable arc from 40° to 360° to keep water in the appropriate areas
• Standard factory-installed 2.0 nozzle speeds installation
• QuickCheck™ Arc Mechanism for fast arc adjustment
OPERATING SPECIFICATIONS
• Nozzle choices: 8
• Radius: 15′ to 34′
• Flow: 0.42 to 4.3 GPM
• Recommended pressure range: 30 to 50 PSI
• Operating pressure range: 20 to 100 PSI
• Precipitation rate: 0.6 in/hr approximately
• Nozzle trajectory: 14° approximately
• Warranty period: 2 years
FACTORY-INSTALLED OPTIONS
• Drain Check Valve (up to 7′ of elevation) excluding PGJ-00
• Reclaimed water ID
